75 Inch Capacitive Multi Touch Screen
Product Parameter
|
Outline dimension |
1674.9(L) × 958 (W) |
|
Action area |
1654.66(L) × 933.24(W) |
|
Inch size |
75″ |
|
Interface types |
USB/UART |
|
Structure type |
GFF (Metal mesh Film) |
|
Thoroughfare |
TX: 80 RX: 142 |
|
First floor |
125um OCA |
|
Second floor |
125um Film |
|
The third layer |
125um OCA |
|
The fourth layer |
125um Film |
|
Aggregate thickness |
0.5mm |
|
Working temperature |
-10℃～60℃ |
|
Storage temperature |
-20℃～70℃ |
|
Executive system |
Android/Windows |
|
Touch point number |
40 Points |
|
Touch accuracy |
±3mm |
|
Degree of linearity |
±3mm |
|
Transmissivity |
≥83% |
Application Scenarios
It is suitable for touch control module, smart blackboard, mutual animal joint blackboard, smart classroom interactive blackboard, digital signage, outdoor advertising machine, game entertainment, new retail and other applications.
Product Superiority
1. It is the suitable technology with the highest cost performance, the longest life, the simplest use and the large-scale verification in the field of 3D printed capacitors touch screen.
2. Simple process, high yield.
3. High efficiency, convenient fitting glass cover plate, very few manufacturing process, only need a simple fitting tools.
4. Bendable, easy maintenance and other advantages that traditional capacitive screens do not have.
5. Insensitive to the external light, the light changes will not affect.
6. Strong stability, easy to maintain, multi-touch, waterproof and dust-proof, strong light, wearing gloves can also be touch.
