86 Inch Capacitive Multi Touch Screen
Product Description
The 86-inch touch screen can reach more than 10 fingers of interactive experience. The original handwriting writing and touch interaction products can be applied in office meeting, drawing, design, animation, financial paperless office and other human-computer interaction related fields.
Support for Windows, Android, Linux, macOS, Raspberry Pi and other systems.
Product Parameter
|
Outline dimension |
1925.16(W) × 1096.74 (L) |
|
Action area |
1901.04(W) × 1071.96(L) |
|
Visible range |
1897.04(W) × 1067.96(L) |
|
Inch size |
86″ |
|
Interface types |
USB/UART/IIC |
|
Structure type |
FF (Metal mesh Film) |
|
First floor |
No cover plate |
|
Second floor |
125um OCA |
|
The third layer |
125um FiIm |
|
The fourth layer |
125um OCA |
|
The fifth layer |
125um FiIm |
|
Touch point number |
40 Points |
|
Touch accuracy |
±2mm |
|
Transmissivity |
≥86% |
