65 Inch Capacitive Multi Touch Screen
Product Description
This is a 65-inch capacitive touch screen solution, which mainly supports Windows, Android, Linux, macOS, Raspberry Pi and other systems.
Product Parameter
|
SENSOR (OD) |
1470.4(L) × 850.6 (W) |
|
SENSOR (AA) |
1438.4(L) × 813.6(W) |
|
Inch size |
65″ |
|
Structure type |
FF (Metal mesh Film) |
|
Thoroughfare |
TX: 78 RX: 138 |
|
First floor |
125um OCA |
|
Second floor |
125um Film |
|
The third layer |
125um OCA |
|
The fourth layer |
125um Film |
|
Aggregate thickness |
0.5mm |
|
Working temperature |
-10℃～60℃ |
|
Storage temperature |
-20℃～70℃ |
|
Transmissivity |
≥86% |
Reliability
High temperature storage: 70℃, 240hrs, Placed in room temperature 4h, the sample was tested.
Low temperature storage: -20℃, 240hrs, Placed in room temperature 4h, the sample was tested. (Non-condensing)
Storage temperature / humidity: 65℃/90% RH, 72hrs (Non-condensing)
Hot and cold impact: -20℃～70℃, 60min/cycles, Start with cold temperature and end with high temperature.
